• 3.3 V, 2.5 V and 1.8 V VDD supply operation

• LVPECL, LVDS, HCSL, AC Coupled CML output options available on differential output pads

• Best in class PSRR performance of -85 dBC

• +/- 50 ppm stability (-40°C to 85°C)

• Output tri-state (Output Enable) function available on Pin 1 of the package

• FTTR/PON

• 1 G / 10 G optical ethernet

• SDI broadcast video

• Industrial

• Datacenter

• Test and measurement

• Wide output frequency (200 kHz – 200 MHz) can be factory programmed to meet diverse applications including 5G base stations, optical modules, and industrial controls

• Low jitter performance ensures high-speed signal integrity, and precision timing in high-speed ADC/DAC systems

• Excellent PSRR performance provides system robustness and enables simple power supply filtering design

• Pin compatible with industry standard package XO in 6-Pin package to ensure easy adoption

• Short lead time: Samples qty: <2 weeks; Production qty: <8 weeks
